380V RACK Abugun Ajọ
Ṣe o nilo aaye agbesoke giga 380v ti nṣiṣe lọwọ Sitelo? Geyo pese awọn solusan, gbẹkẹle awọn solusan ti o ta si awọn aini rẹ. Pẹlu awọn atunto ti o gapọ, idaniloju didara, ati ifijiṣẹ iyara, a ṣagbe si ọpọlọpọ awọn ibeere alabara. Kan si wa bayi fun awọn idiyele osunwon ati iṣẹ ori ayelujara 24-wakati.
Àlẹmọ ti 380V Awọn agbesoke Olumulo ti nwọle lọwọlọwọ (AHF) n pese ohun-ini ti ilọsiwaju mitiation fun mẹta-phase mẹrin-ware (3P4W) ati mẹta-alakoso-ina-mẹta (3p3W) Awọn ọna agbara. Lilo iṣakoso DSP + CPL oni-nọmba ati ipele mẹta Topology, ọkan ti a gbekele afeke ti a fi agbara jẹ adehun deede isanpada soke si 50 intlankora. Apẹrẹ iṣan-ara ṣe atilẹyin ti o jọra asopọ fun agbara pọ ati itọju irọrun. Lọpọlọpọ Awọn awoṣe wa pẹlu awọn idiyele ti isiyi lati 25a si 150a, ti n ba sọrọ Awọn ọpọlọpọ awọn ibeere eto agbara. Fi agbara mu itutu air ṣe idaniloju ti o gbẹkẹle isẹ paapaa labẹ awọn ipo ibeere. Ipele agbesoke 380V yii n ṣiṣẹ Àlẹmọ ohun-ini nfunni ni ojutu kan ti o ni ibamu fun arabara iparun.
Apejuwe awoṣe:
| Gy | Ahf | 0.4 | 50A | / | 4l | R |
| Koodu ile-iṣẹ | Àlẹmọ faragba ti nṣiṣe lọwọ | Ipele folti 0.4: 380v ± 20% |
Agbara ti o ni oṣuwọn (Kvar) 25/50/75 / 100 / 150a | 3L: mẹta-phase mẹta-okun waya 4L: mẹta-phase mẹrin-waya |
R: agbeko ikogun |
Awọn ẹya:
Lo DSP + CPLD Gbogbo Core Digital Founta, Imọ-ẹrọ Towelogy mẹta-ipele,
Ilọsiwaju aladani ti ilọsiwaju Atgorithm ati ilana iṣakoso PWM lati ṣaṣeyọri
isanpada deede ti Ul UNTAL.
● Gba apẹẹrẹ iṣiro, eyiti o mu isopọ asopọ ti o ni afiwe
Awọn modulu, gba aaye kekere ati rọrun lati ṣetọju.
● Awọn apẹrẹ igbekale ti awọn iyami afẹfẹ ominira ati awọn iwa-ọfẹ ọfẹ
ṣe idaniloju iṣẹ iduroṣinṣin ti ẹrọ.
O le ṣe àlẹmọ awọn apejọ ni ọpọlọpọ awọn ohun-ini, lati 2 si 50
Ipalara, ati yanju iṣoro ti aiṣedeede mẹta lẹsẹsẹ ni akoko kanna.
Iwọn iṣiro fifẹ ti o ga julọ ga. Ti agbara naa ba gba laaye, ara ẹni
Oṣuwọn sisẹ lọwọlọwọ le jẹ giga bi 95%. Ṣeto 100% diduro
Iyọ lati rii daju iṣẹ iduroṣinṣin igba pipẹ ti ẹrọ.
Awọn ohun elo:
380V agbeko Aboju awọn asia Hantigbọ ti o nwọle ti wa ni gbigbe kọja kọja ọpọlọpọ Awọn ọja lati rii daju didara agbara ati iduroṣinṣin eto:
● Awọn ile-iṣẹ data:Idaabobo awọn olupin pataki-pataki ati
Ẹrọ nẹtiwọọki lati inu awọn ọran ti o ni ibatan si.
● Awọn agbegbe Iṣẹ Iṣẹ:Imudarasi iṣẹ ati
igbẹkẹle ti awọn awakọ igbohunsafẹfẹ ayípadà (VFDs) ati awọn miiran-laini
awọn ẹru.
● Awọn irugbin iṣelọpọ:Imudarasi agbara agbara ati idinku
lilo agbara.
● Ororo ati gaasi:Ṣetọju agbara iduroṣinṣin fun ifura
awọn eto iṣakoso ilana.
380V agbeko Abora ti o nṣiṣe lọwọ awọn Ajọ alailera ifijiṣẹ fi nipa mi ati didara agbara igbẹkẹle fun awọn ohun elo ibeere.
Awọn ohun elo imọ-ẹrọ:
| 220vn jara | 380V Series | 500ye jara | 690v jara | ||
| Ibi giga | <2000m, loke 2000m, o dara julọ ni ibamu si GB / t3859.2 | ||||
| Otutu otutu | -20 ~ + 50 ℃ | ||||
| Ọriniinitutu ibatan | ≤90%, ko si condensation lori dada nigbati oṣooṣu Iwọn otutu ti o kere ju jẹ 25 ℃ | ||||
| Ipele idoti | Ipele III ni isalẹ | ||||
| Foliteji ṣiṣẹ | Ac220v ± 20% | Ac380v ± 20% | Ac500v ± 20% | Ac690v ± 20% | |
| Ibi igbohunsafẹfẹ | 50hz ± 5% | ||||
| Isina lọwọlọwọ | 2 | 25/50/75/100 / 150a | 100A | 100A | |
| Si be | L / n | 3p3W / 3P4W | 3p3W / 3P4W | 3p3W / 3P4W | |
| Nọmba ti awọn sipo ti sopọ ni afiwe |
Olimuted | ||||
| Gbogbogbo ẹrọ ẹrọ | ≥97% | ||||
| Si be | 32khz | 16khz | 12.8khz | 12.8khz | |
| Iwoye isanwo | 2 ~ 50times, oṣuwọn isanpada kan jẹ adijositable | ||||
| Aṣayan iṣẹ | Agbara atunse | Agbara imulo, Agbara atunse + Asymmetry | |||
| Agbara atunse oṣuwọn isanpada |
≥95% | > 92% | |||
| Isẹkuro Neught agbara |
Agbara laini ṣiṣi silẹ laini jẹ awọn akoko 3 ti alakoso Sisẹ agbara | ||||
| Akoko idahun ni kikun | <10Ms | <40ms | <40ms | <40ms | |
| Ariwo | ≤60DB | ≤60DB | ≤65DB | ≤65DB | |
| Ọna iṣakoso | 2-ọna RS485 ni wiwo (ṣe atilẹyin GPRS / WiFi) | ||||
| Idaabobo | Apọju, software / Hardcurrent, Ikun Overvoltage ati ikuna, ikuna agbara, o ko le yọ, igbohunsafẹfẹ Idaabobo ajeji, bbl | Apọju, software / Hardcurrent, Ikun Overvoltage ati aiṣedeede, aiṣedeede folda, ikuna agbara, Iyọ, ibigbogbo igbohunsafẹfẹ, Circuit kukuru Idaabobo, bbl | |||
| Ọna fifi sori ẹrọ | Agbeko / ogiri-ogiri | Agbeko | |||
| Laini ti nwọle | Pada ti nwọle (iru agbeko), ti nwọle ti o wa (oke-oke) | Laini ti nwọle | |||
| Ipele Idaabobo | Ip20 | ||||
Awoṣe & Alayeyeyeye:
| Awoṣe | ||||
|---|---|---|---|---|
| Nọmba Awoṣe | Ti o wa lọwọlọwọ (a) | Folti foonu (v) | Awọn iwọn (D * W * h) | Ọna itutu agbaiye |
| Gy apf-0.22-25a / 2L-R / W | 25 | 220 | 220 * 330 * 160mm | Fi agbara mu itutu afẹfẹ |
| Gy APF-0.4-25a / 4L-R / W | 25 | 380 ± 20% | 460 * 490 * 89mm | |
| Gy APF-0.4-50A / 4L-R / W | 50 | 380 ± 20% | 460 * 490 * 89mm | |
| Gy APF-0.4-75a / 4L-R / W | 75 | 380 ± 20% | 500 * 510 * 190mm | |
| Gy APF-0.4-100a / 4L-R / W | 100 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy APF-04-150a / 4L-R / W | 150 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy APF-0,5a / 4L-R / W | 100 | 500 ± 20% | 495 * 675 * 275mm | |
| Gy APF-0.69-100a / 4L-R / W | 100 | 690 ± 20% | 495 * 675 * 275mm | |
